Chicken, Rice & Butternut
Small portions · visual reconstruction

Sleeve slides sideways first; film and food lift next.

Drag to orbit · wheel / pinch to zoom · right-drag / two fingers to pan
Keyboard: arrows orbit · Shift + arrows pan · + / − zoom

Inspector No selection

Made to be explored.

Select a part in the model or assembly list to examine its construction, materials and artwork.

Dimensions are estimates.
This is a visual study, not a production specification.
Inspection modes

Keep your inspection

1 scene unit = 1 mm
Y up · X left/right · +Z front

Reference comparison

Updated concept · small square portions. Inset shows the same package.

Updated product reference, with four small chicken pieces and four butternut cubes visible around the kraft sleeve

Sleeve artwork

Editable SVG printing on natural kraft. Estimated layout, not a production dieline.

Download editable SVG
Top sleeve artwork

How the sleeve folds

Illustrative flat strip · all extents estimated

Top 105 × 228 mm
Front fold ≈ 39 mm
Bottom 105 × 228 mm
Rear fold ≈ 39 mm

Rounded crease allowance ≈ 6 mm each.
Board thickness ≈ 0.55 mm.

Connect the strip into a tunnel. Leave both X ends open; slide sideways over the tray.

Hidden seam / glue overlap inferred. No manufacturing tolerance or glue allowance is established.

Export ready

Preview the exact file below. Use Save file if your browser did not start the download.

Save file
